If that frame isn’t a certified Fire‑Resistant Door Frame, heat can warp it, smoke can slip through its edges, and the entire door—no matter how advanced—can fail. A weak frame bends, cracks, or collapses long before the fire-rated door itself reaches its limit.
This is why a fire door doesn’t work alone.
It performs its life-safety function only when supported by a properly tested fire proof door frame—one strong enough to resist extreme heat, stay structurally stable, and seal out dangerous smoke. Without it, fire protection is an illusion, and seconds that matter most are lost.
A compliant fire proof door frame (metal or engineered timber), installed as per IS 3614:2021 or BS 476 Part 22, ensures:
- Integrity (the door stays in place)
- Insulation (heat does not travel rapidly through the frame)
- Smoke control (gaps remain sealed under fire conditions)
When selecting the right frame, evaluate its material, fire-rating duration, construction method, certifications, and the project’s risk category.
Why the Door Frame Is Critical in Fire Safety
Fire-rated frame maintains structural integrity during fire.
A fire-rated door leaf cannot protect occupants unless the door frame is equally fire-resistant. A regular timber or metal frame may warp, melt, or collapse when exposed to high temperatures, allowing fire and smoke to pass.
Why a certified fire resistant door frame matters:
- Structural stability: Under fire, a weak frame may twist or collapse — compromising the entire doorset.
- Smoke & heat containment: A certified fire resistant door frame includes intumescent seals that expand to close gaps.
- System synergy: Door leaf + fire frame + hardware + seals must be certified together. Changing any component can invalidate the fire rating.
Fire-Rated Frame vs Regular Frame
Fire-rated frame maintains structural integrity during fire.
A fire-rated door leaf cannot protect occupants unless the door frame is equally fire-resistant. A regular timber or metal frame may warp, melt, or collapse when exposed to high temperatures, allowing fire and smoke to pass.
Feature | Fire-Rated / Fire Resistant Door Frame | Regular Frame |
Heat Resistance | Designed for sustained high temperatures | Warps/melts quickly |
Structural Stability | Holds the door in place during fire | Likely to deform |
Smoke & Gas Containment | Uses tested intumescent seals | Allows smoke to pass |
Certification | Fully tested as a fire-proof door frame system | No certification |
Real-World Performance | Provides evacuation time & compartmentation | Can fail early, spreading fire |
Key Factors to Evaluate When Choosing a Fire-Resistant Door Frame
1. Material Type (Steel, Wooden, Composite)
A well-chosen material strengthens performance and long-term durability of your fire door frame.
Material | Durability & Fire Performance | Cost | Aesthetics / Use Case |
Steel / Metal Fire Door Frame | Maximum stability, ideal for high-risk zones | Medium–High | Modern/industrial look |
Wooden / Engineered Timber Fire Resistant Door Frame | Certified timber withstands fire when engineered & treated properly | Medium | Warm aesthetics — hotels, residences |
Composite Fire Proof Door Frame | Balanced performance with engineered fire cores | Medium | Flexible finishes for design-heavy spaces |
2. Use-cases:
- Steel fire-resistant frames → hospitals, high-rise buildings, industrial premises
- Timber fire frames → hotels, offices, premium residential
- Composite frames → mixed-use projects needing durability + design
2. Fire Rating Duration (30 / 60 / 90 / 120 minutes)
Each fire rating corresponds to specific project needs:
Contact
Us
Have a question or feedback?
Fill out the form below, and we’ll respond promptly!
Call us or fill out our form
+91 84200 50758
- FD30 (30 min) → Low-risk areas, small residential units
- FD60 (60 min) → Corridors, staircases, commercial spaces
- FD90 (90 min) → Schools, large commercial buildings
- FD120 (120 min) → Hospitals, data centers, industrial plants
Higher occupancy requires higher fire proof door frame rating.
Always align selection with NBC guidelines, occupancy load, and evacuation strategy.
3. Certification & Testing Standards
A fire resistant door frame must be certified as part of a complete fire doorset.
Certification Checklist
Certification Checklist
- IS 3614:2021 (India)
- BS 476 Part 22 / EN 1634 (International)
- UL 10C (High-performance fire doorsets)
- Third-party accredited lab test reports
- Correct frame–leaf–hardware compatibility
- Manufacturer’s rating label and ISI mark
4. Frame Construction & Fill Material
To ensure reliable fire performance, check:
Certification Checklist
Certification Checklist
- Rebated or mitered joints for enhanced structural lock
- Fire-retardant core material inside timber or composite frames
- Intumescent seals that expand under heat
- High-density engineered timber (for wooden frames)
- Low moisture content (<12%) to prevent warping
Think of the doorset as a single engineered fire-protection system.
5. Project-Specific Requirements
Different industries demand different fire proof door frame solutions:
Hospitals
High occupancy + vulnerable people → FD60–FD120 metal/timber fire-resistant frames.
Hotels / Hospitality
Aesthetic timber fire frames preferred, but staircases need FD60+
Schools / Offices
Moderate risk → FD30–FD60 depending on building layout.
Cinemas / Auditoriums
High density → FD90–FD120 frames with smoke seals.
Industrial / Factories
High fire-load → Steel fire door frames with FD120+ rating.
Metal vs Wooden Fire-Resistant Frames: How to Decide
Metal Fire Door Frame
Extremely stable under fire
Moisture-resistant
Best for: Hospitals, factories, high-rise buildings
Wooden Fire Resistant Door Frame
Aesthetic interior-friendly look
Easy installation
Best for: Hotels, offices, homes
Need maximum fire/smoke containment? → Metal fire proof door frame
Need aesthetics + compliance? → Certified wooden fire resistant door frame
Need balance? → Composite fire door frame
Common Mistakes to Avoid When Selecting Fire Door Frames
Top 5 Mistakes:
- Using a regular frame with a certified fire door
- Mixing uncertified components (invalidates test results)
- Ignoring intumescent seals
- Installing on weak/incompatible walls
- Substituting hardware not listed in the certification report
Wrong frame causes fire doorset failure.
Why Certified tufwud Fire-Resistant Frames Make Compliance Easier
Advantage:
- Fully-certified fire door + fire door frame systems
- High-density engineered timber fire resistant frames
- Metal and wooden frame options for all risk categories
- Proven performance in hospitals, hotels, cinemas
- Design freedom + life-safety assurance
Benefit
- Built to protect lives
- Engineered for design flexibility
- Tested as a complete fire-proof door frame system
- Ensures compliance with IS 3614 & BS 476
FAQ
What certifications should I check?
IS 3614, BS 476 Part 22, EN 1634, UL 10C — along with test reports.
Can any wall hold a fire door frame?
No. Wall type must match the tested installation conditions.
Can wooden frames be fireproof?
Yes, when engineered, tested, and certified as a fire resistant door frame.
